İndüktif Sensör M30 10mm Algılama 2 Metre Kablolu 12...48VDC XSAV11373
Satış Fiyatı
5.882,15 TL
(KDV DAHİL)
5.882,15 TL den
başlayan taksitlerle!
başlayan taksitlerle!
Veri sayfası
Ana
Range of product
Telemecanique Inductive proximity sensors XS
Series name
Application
Product or component type
Sensor
Sensor type
Inductive proximity sensor
Sensor name
XSA
Device application
Rotation monitoring
Sensor design
Cylindrical M30
Size
81 mm
Body type
Fixed
Type of output signal
Discrete
Wiring technique
3-wire
Discrete output function
1 NC
Detector flush mounting acceptance
Flush mountable
Discrete output type
PNP
Material
Metal
Electrical connection
Cable
[Us] rated supply voltage
12...48 V DC with reverse polarity protection
Output circuit type
DC
Switching capacity in mA
<= 200 mA with overload and short-circuit protection
IP degree of protection
IP67 conforming to IEC 60529
Tamamlayıcı
Enclosure material
Nickel plated brass
Detection face
Frontal
Thread type
M30 x 1.5
Front material
PPS
Sensing range
8...15 mm
Differential travel
3...15% of Fr
Repeat accuracy
<= 3% of Sr
Cable composition
3 x 0.34 mm²
Status LED
Output state: 1 LED (red)
Wire insulation material
PVC
Switching frequency
<= 100 Hz
Voltage drop
<1.8 V (closed)
Current consumption
0...15 mA no-load
Marking
CE
Ortam
Product certifications
CCC
CSA
UL
CSA
UL
Paket Birimleri
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.1 CENTIMETER
Package 1 width
9.5 CENTIMETER
Package 1 length
13.2 CENTIMETER
Package 1 weight
0.229 KILOGRAM
Unit type of package 2
S02
Number of units in package 2
22
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
5.35 KILOGRAM
Unit type of package 3
CAR
Number of units in package 3
1
Package 3 height
13.2 CENTIMETER
Package 3 width
4.1 CENTIMETER
Package 3 length
9.5 CENTIMETER
Package 3 weight
0.23 KILOGRAM
Indivisible sale quantity
1
